The Guide to 3D Printing with Inconel
Inconel, a high-performance superalloy, is widely used in industries that demand exceptional strength, heat resistance, and corrosion protection.
Inconel 625 and Inconel 718 have become popular choices for producing intricate, durable components through Laser Powder Bed Fusion (LPBF). This guide covers the advantages, material options, and key post-processing techniques for 3D printing Inconel.
Advantages of Inconel 3D Printing
Inconel 3D printing offers several benefits, particularly for industries requiring high performance in extreme environments.
High-temperature resistance: Inconel’s ability to withstand extreme temperatures makes it ideal for engine components, turbines, and other high-heat applications.
Corrosion resistance: Inconel’s remarkable resistance to oxidation and corrosion is critical for harsh environments like chemical plants, marine applications, and gas turbines.
Complex geometries: LPBF allows for intricate designs, such as cooling channels or lattice structures, that are difficult or impossible to achieve with traditional manufacturing methods.
Material efficiency: 3D printing uses only the material needed for the part, minimizing waste and reducing material costs.
Faster lead times: 3D printing accelerates the production process without complex tooling, making it ideal for prototyping and low-volume production.
Start Your Manufacturing Project with MakerVerse
MakerVerse is your platform for sourcing industrial parts, providing instant access to a vetted supply chain and a full range of manufacturing technologies. With AI-powered quoting, order management, and fulfillment, MakerVerse helps with everything from initial prototypes to full-scale production.
Common Materials for Inconel 3D Printing
Inconel comes in several alloy compositions, but Inconel 625 and Inconel 718 are the most used on the MakerVerse platform.
Inconel 625
Inconel 625 (IN625) is a nickel-based non-ferrous alloy with good performance in high-temperature environments and exceptional resistance against oxidation. This is mainly because IN625 has less iron and a higher chromium concentration than other alloys. Further, IN625 can withstand high temperatures, much like other nickel superalloys.
Inconel 625 Properties | Value |
---|---|
Yield Strength Rp 0.2% | 630-690 MPa |
Ultimate Tensile Strength Rm | 850-950 MPa |
Elongation at Break | 29-39% |
Young’s Modulus | 170-230 GPa |
Relative Density | >99.5% |
Inconel 625’s combination of corrosion resistance and high strength allows it to perform well in demanding conditions, particularly in saltwater and chemical environments.
Inconel 718
Inconel 718 (IN718) is a nickel-based superalloy with good performance in high-temperature environments. This is mainly because IN718 has good mechanical properties up to 700 °C. Furthermore, the metal has excellent oxidation and corrosion resistance, making it ideal for use in demanding environments. Another advantage is the high strength of the material.
Property | Value |
---|---|
Yield Strength Rp 0.2% [MPa] | 560-770 |
Ultimate Tensile Strength Rm [MPa] | 870-1050 |
Elongation at Break [%] | 22-32% |
Young’s Modulus [GPa] | 150-188 |
Hardness | 47 HRc |
Inconel 718 is particularly valuable for its ability to retain strength at high temperatures, making it a top choice for applications that endure extreme heat and stress.
Post-Processing Techniques for Inconel 3D Printing
Post-processing is a crucial step in enhancing the mechanical properties, durability, and surface finish of Inconel parts. These are the most commonly used post-processing techniques for Inconel 625 and Inconel 718 on the MakerVerse platform.
Heat treatment: Heat treatment is vital in improving Inconel’s mechanical properties. This process enhances strength and high-temperature performance by precipitating hardening phases. Heat treatment can also improve overall stress resistance, making parts more durable in demanding environments.
Polished: Polishing is essential for achieving a smooth, reflective surface on Inconel parts. This is particularly important for components in high-wear applications, such as turbine blades or engine parts, where surface finish affects performance.
Tumbled: Tumbling is a process that smooths out rough surfaces and removes sharp edges from complex geometries. It is especially useful for parts with intricate designs or internal channels, ensuring a uniform, matte finish throughout.
Painted: Painting Inconel parts adds a protective layer that improves aesthetic appeal. This is especially beneficial for consumer-facing products.
CNC machined: CNC machining is often used to fine-tune 3D-printed Inconel parts, ensuring precision in critical areas like holes, threads, and tight tolerances. It provides the exact dimensions and smooth surfaces required for high-performance applications, especially in aerospace or medical industries.
Start Your Project with MakerVerse
Inconel 3D printing allows you to create high-performance parts that withstand extreme conditions. Whether you need a prototype or are ready for full-scale production, MakerVerse offers cutting-edge tools, materials, and expertise to bring your Inconel parts to life. Discover how Inconel 625 and Inconel 718 can transform your next project.
